“Shock resistant” supporting perimeter chassis ensures
maximum exploitation of induction motor torque.
• Complete automotive lighting and signal system. Led lights.
• Suspensions: rubberised steel coil springs in the front, steel
coil springs with shock absorbers in the rear.
• Drum service brake acting on 4 wheels with twofold braking
system. Electromagnetic parking brake. Preset electrical
braking, operating automatically when accelerator pedal is
released, with first stroke of brake pedal and on reversing
direction.
• Mechanical steering. Hydraulic steering available upon
request.
• 1 operator on board. Optimised driving position for maximum
comfort and efficiency as well as user-friendly and ergonomic
dashboard. Passenger seat available upon request.
• “Man on board” device with seat occupancy sensor. Available
in basic version, with weather protection roof with front
windscreen and electric wipers. PVC canvas doors or cab with
hinged side doors available.

 Lighting system: 2 front lights (dipped-beam/main-beam),
2 front turn indicators, 2 rear turn indicators, 2 rear lights
(position/brake lights). Full LED technology. Horn. Flashing
light, reversing light and blue lights available upon request
• Digital dashboard with battery charge indicator, fault detection,
speedometer and hour meter. 24 V DC/DC converter for
auxiliary services.
• Induction motor equipped with encoder, thermal probes and
negative electromagnetic parking brake with manual brake
disengage lever.
• Electronic speed control of AC motor with energy recovery
during deceleration and braking. Several towing hitches
available. Rear inching control to ease coupling operations.
• Battery DIN 43531A 48 V - available capacity 315Ah, 345Ah
and 375Ah. Standard paint finish: chassis dark grey RAL
7021/body light grey RAL 7035. Other colours available upon
request.

 “Shock resistant” supporting perimeter chassis ensures
maximum exploitation of induction motor torque.
• Suspensions: rubberised steel coil springs in the front, SUMOR
springs in the rear.
• Drum service brake acting on 4 wheels with twofold braking
system. Electromagnetic parking brake. Preset electrical
braking, operating automatically when accelerator pedal is
released, with first stroke of brake pedal and on reversing
direction.
• Standard hydraulic steering.
• 2 operators on board. Optimised driving position for maximum
comfort and efficiency, low step-on platform for comfortable
access as well as user-friendly and ergonomic dashboard.
• “Man on board” device with seat occupancy sensor. Available
in the basic version, with weather protection roof with front
windscreen and electric wiper. PVC canvas doors or cab with
hinged or sliding side doors availableLighting system: 2 front beams (dipped-beam/main-beam), 2
front turn indicators, 2 rear turn indicators, 2 rear beams (tail/
brake lights). Full LED technology. Horn. Flashing light, rever -
sing light and blue lights as well as cab lights available upon
request.
• Digital dashboard with battery charge indicator, fault detection,
speedometer and hour meter. 24 V DC/DC converter for
auxiliary services.
• 2 induction motors equipped with encoder, thermal probes
and negative electromagnetic parking brake.
• Electronic speed control of AC motor with energy recovery
during deceleration and braking. Several towing hitches
available. Rear inching control to ease coupling operations.
• Battery DIN 43531B 48 V - available capacity 525Ah, 575Ah
and 625Ah. Battery fitted behind driving position for fast repla -
cement from above. Standard paint finish: chassis dark grey
RAL 7021/body light grey RAL 7035. Other colours available
upon request.

“Shock resistant” supporting perimeter chassis ensures
maximum exploitation of induction motor torque.
• Suspensions: steel coil springs, stabiliser bar and shock
absorbers in the front and in the rear.
• Drum service brake acting on 4 wheels - with twofold braking
system. Front disk brakes and rear oil-bath multiple-disk
brakes. Mechanical lever-type parking brake - negative hydrau -
lic brake available upon request. Preset electrical braking,
operating automatically when accelerator pedal is released,
with first stroke of brake pedal and on reversing direction.
• Standard hydraulic steering.
• 2 operators on board. Comfortable driving position ensures
excellent visibility both to the front and to the rear towing hitch.
• “Man on board” device with seat occupancy sensor. Available
in basic version, with weather protection roof with front
windscreen and electric wipers. PVC canvas doors or cab with
hinged side doors available.

• Lighting system: 2 front lights (position/dipped-beam/
main-beam), 2 front turn indicators, 2 rear turn indicators,
2 rear lights (position/brake lights), 2 reversing lights. Horn.
Flashing light and blue lights available upon request.
• Digital dashboard with battery charge indicator, fault
detection, speedometer and hour meter. 24 V DC/DC converter
for auxiliary services.
• Induction motor with through shaft integrated into driveline.
• Electronic speed control of AC motor with energy recovery
during deceleration and braking. Several towing hitches
available. Rear inching control to ease coupling operations.
• Battery DIN 43536A, 80 V – a 480 -vailable capacity 620Ah.
Battery in the front of the driver’s cab for fast replacement from
the side. Standard paint finish: chassis dark grey RAL 7021/body
lig t grey RAL 7035. Other colours available upon request
