“Shock resistant” supporting perimeter chassis ensures
maximum exploitation of induction motor torque.
• Suspensions: rubberised steel coil spring in the front, rubber
silent block in the rear.
• Drum service brake acting on 3 wheels with twofold braking
system. Electromagnetic parking brake. Preset electrical
braking, operating automatically when accelerator pedal is
released, with first stroke of brake pedal and on reversing
direction. Fifth wheel mechanical steering.
• 1 operator on board. Optimised driving position for maximum
comfort and efficiency, low step-on platform for comfortable
access as well as user-friendly and ergonomic dashboard.
• “Man on board” device with seat occupancy sensor. Available
in basic version, with weather protection roof with front
windscreen and electric wipers. PVC canvas doors or cab with
hinged side doors available.

Lighting system: 2 front lights (position/dipped-beam/
main-beam), 2 front turn indicators, 2 rear turn indicators, 2
rear lights (position/brake lights). Horn. Flashing light, rever -
sing light and blue lights available upon request.
• Digital dashboard with battery charge indicator, fault detection,
speedometer and hour meter. 24 V DC/DC converter for
auxiliary services.
• Induction motor equipped with encoder, thermal probes and
negative electromagnetic parking brake with manual brake
disengage lever.
• Electronic speed control of AC motor with energy recovery
during deceleration and braking. Several towing hitches
available. Rear inching control to ease coupling operations.
• Battery DIN 43531A 48 V - available capacity 315Ah, 345Ah
and 375Ah. Standard paint finish: chassis dark grey RAL
7021/body light grey RAL 7035. Other colours available upon
request.
